Indicateur de capacité Bluetooth 0-120V 400A

Bluetooth RS485 10V-120V capacity indicator for all types of batteries.

This capacity indicator (coulombmeter) is designed to measure various parameters such as voltage, current, power, charge and discharge capacity, watt-hours and time.

At the same time, it can set parameters to obtain various protections: protection against overvoltage and undervoltage, protection against overcurrent and overtemperature.

The meter can automatically identify the direction of the current, monitor battery capacity in real time and display measured data via Bluetooth. It can also control meter and firmware upgrades via the mobile app. It can communicate via an RS485 link.

The maximum Bluetooth communication distance is 10 metres.

TECHNICAL SPECIFICATIONS

400A shunt current measurement

Voltage range (external power supply) : 0-120V
Measuring range (self-powered) : 10-80V
Power range : 0-72KW
Voltage resolution : 0.01V
Current measurement : 0-400A
Current resolution : 0.01A
Weight : 527g

STANDARDS

Certifications : RoHS I CE

Warranty - 2 years
